Name: TruSteel AV-300 AutoVap Falling Film Evaporator - 300 Gal/Hr
Brand: TruSteel
SKU: AV-300
Price: 974999 USD
Availability: OutOfStock

Description

With a recovery rate of over 300 gallons per hour, and continuous, automated operation, the AV300 recovers 95%+

solvent on the first pass. Lower your footprint, costs, and time of operation while eliminating any bottlenecks with the AutoVap. Find out why all the leaders in the extraction industry are turning to TruSteel. The AutoVap300 recovers heat from evaporation and uses it to preheat the feed stock. It also uses the temperature differential of the feed liquid to partially condense the vapor from evaporation.Colder feed stock will increase the performance, and allows the energy required to achieve subzero temperatures to be recovered and reused.

STANDARD FEATURES	SPECIFICATIONS
• Up to 300 US Gal/HR Recovery* • 95-99% Removal 1st Pass • <3 Minute Residence Time • Fully Automated Operation • Fail Safes, Alarms, Data Logging, Remote Control • Material: Stainless Steel, PTFE, & Borosilicate • Compatible With: Ethanol, Methanol, Heptane, Hexane, Acetone, Acetonitrile • UL Listed Ancillary Equipment Included: Heating System, Cooling System, and Vacuum • Solvent Resistant Touch Screen • Engineer Reviewed for Safe Operation in Hazardous Locations • USA and Canadian UL Listed • Installation, Training & Support Included • 1 Year Warranty	CHILLER (80 TON COOLING POWER) 460V/3Ø/156A 181 x 86 x 85 (LxWxH inches) 6279 lbs. (empty weight)
	COMPRESSED VAPOR RECOVERY Powered by PLC
	WATER HEATER SKID 72 x 96 x 48 (LxWxH inches)
	WATER PUMP CONTROL PANEL 230-240V/3Ø/28A OPTION 1: ELECTRIC 480V/3Ø/362A OPTION 2: GAS 1.2M BTU - 2” GAS CONNECTION
	CONTROL PANEL [PLC] 208-240V / 3ø / 30A 8 x 36 x 48 (LxWxH inches)
	AUTOVAP300 FOOTPRINT 36 x 75 x 126 (LxWxH inches)
	* Rated for Ethanol Recovery Different solvents may result in varied recovery rates. Heptane/Hexane typically recovers 50% faster than Ethanol.
